Apollo AIPHD-P7503 LCD Video Wall Commercial-Grade Display

AIPHD-P7503 Copied!

• 150-inch true 8K with 2x2 seamless splicing

• Ultra-thin 3.5mm bezel for borderless visuals

• Local dimming for ultra-high contrast clarity

• 178° wide-angle viewing, vivid color accuracy

• 50,000-hour LED lifespan, commercial reliability

•True 8K (7680×4320) 150-inch solution

Technical Specifications

AIPHD7503 Professional Display Specifications
Active Display Area	1649.66mm(H) × 927.93mm(V)
Bezel Width	3.5mm
Resolution	3840 × 2160 (UHD)
Brightness	500 cd/m²
Contrast Ratio	1200:1
Response Time	12ms
Viewing Angle	178°(H) × 178°(V)
Display Colors	16.7 Million
Color Gamut	72% NTSC
Light Source	LED (50,000 hours lifespan)
Connectivity	BNC/VGA/DVI/HDMI/RJ45(RS232)
Power Requirements	100-240V 50/60Hz (350W rated)
Operating Environment	0-50°C, 20-80% humidity
VESA Mount	1000 × 600mm compatible
Dimensions	1658.76 × 940.04 × 120.15mm
Net Weight	35kg
Package Configuration	4 units/case: 1820×1190×710mm (175kg)
Standard Accessories	Power Cord, CoC, Warranty Card, User Manual
