Apollo AIPHD-P5504 Video Wall Commercial-Grade Display
AIPHD-P5504
Copied!
Key Features
- 55-inch Full HD display (1920 × 1080 resolution)
- Commercial BOE panel (DV550FHM-NVN)
- Ultra-slim bezel (1.7mm) for near-seamless video wall effect
- Standard brightness 500 cd/m² for clear indoor visibility
- High contrast ratio 4000:1 for sharp image depth
- Fast 8ms response time for smooth video playback
- Wide 178° viewing angle (H/V) for consistent visuals
- 16.7 million colors for rich and accurate image output
- Energy-efficient LED backlight system
• BOE original panel with LED backlight
• 500cd/m² brightness and 178° viewing angle
• Seamless multi-screen splicing capability
• HDMI/DVI/USB signal compatibility
• Smart light adjustment and energy-saving design
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AIPHD-P5504 |
| Screen Size | 55 inches |
| Panel | BOE/DV550FHM-NVN |
| Backlight | LED backlight |
| Resolution | 1920 × 1080 |
| Brightness | 500 cd/m² |
| Contrast Ratio | 4000:1 |
| Response Time | 8 ms |
| Viewing Angle | 178°(H)/178°(V) |
| Display Color | 16.7 Million |
| Weight | 25 kg |
| Power Supply | 100-240V AC, 50/60Hz |
| Maximum Power | ≤240W |
| Standby Power | ≤0.5W |
| Operating Temperature | 0℃ to 50℃ |
| Operating Humidity | 10% to 90% |
| I/O Ports | HDMI ×1, DVI ×1, RS232 IN ×1, RS232 OUT ×2, USB ×1 (Firmware Upgrade) |
| Product Dimensions | 1212.4 × 682.1 × 65.29 mm |
| Bezel Width | 1.7 mm |
| Accessories | Power Cord ×1, Network Cable ×1, Hook ×4, Screw ×8, RS232 Adapter ×1, Remote Control ×1 |
| Certification | CoC, Warranty Card |
