Apollo AIP3588 Q Android 15 Interactive Flat Panel
AIP3588
Copied!
Key Features
- 4K Ultra HD display (65”–86”) with up to 350 nits brightness
- RK3588 Android 15 system with 16GB RAM + 256GB storage
- 20-point infrared touch with fast response (≤5ms) & ±1mm accuracy
- Wi-Fi 6 + Bluetooth 5.0 for smooth connectivity
- Built-in 48MP camera + 8-array microphone for smart meetings
- Multiple ports: HDMI, USB 3.0/2.0, Type-C, DP, LAN
- Smart front controls (voice, annotation, touch lock)
- Anti-glare glass with 30,000-hour lifespan & OPS support
Al Function
• Magic Pen(Al Graphic Conversion)
• OCR Lasso (Handwriting To Text & Search)
• Microsoft Copilot Integration
• Global Handwriting Input
• Screen Shot Text Extraction
WhiteboardAnytime
• Quick Annotation
•Finger/Pen Recognition Differentiation
• Multi-page Annotation
• Annotation Screen Shot Text Extraction
Versatile Canvas
• 3D Model Preview
• Terrestrial Globe 3D/2D
• Shape 2D/3D Convert
• Piano Tool
Technical Specifications
| Model | AP65HSY | AP75HSY | AP85HSY | AP86HSY | ||
| Display parameter | Diagonal Size |  65inch | 75inch | 85inch | 86inch | |
| Effective Display Area | 1428.48(H)*803.52(V) | 1650.24(H)×928.26(V) | 1872(H)×1053(V) | 1895(H)×1066(V) | ||
| Display Ratio | 16:9 | 16:9 | 16:9 | 16:9 | ||
| Brightness | 320cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | ||
| Contrast Ratio | 4000:1 | 4000:1 | 4000:1 | 4000:1 | ||
| Backlight Type | DLED | DLED | DLED | DLED | ||
| Viewing Angle | 178°(V)/178°(H) | 178°(V)/178°(H) | 178°(V)/178°(H) | 178°(V)/178°(H) | ||
| Resolution | 3840（H) X 2160(V) | 3840（H) X 2160(V) | 3840（H) X 2160(V) | 3840(H) X 2160(V) | ||
| Audio Output Power | 8Ω/15W*2 | 8Ω/15W*2 | 8Ω/15W*2 | 8Ω/15W*2 | ||
| Touch | Touch technology | Infrared Multi Touch Technology | ||||
| Touch Points | 20 points touch | |||||
| Drive | HID drive free | |||||
| Writing surface material | 4mm Ag anti glare glass | |||||
| Touch Screen Sensor Mode | Finger, writing pen, hand with gloves or other non transparent touch sensitive medium | |||||
| Resolution | 32768X32768 | |||||
| Communication Port | USB 2.0 | |||||
| Min Recognition Dim | 2mm | |||||
| ResponseTime | ≤5ms | |||||
| Touch Accuracy | ±1mm | |||||
| Anti-Interference | Incandescent lamp (220V, 100W), vertical distance 350mm above, The illumination intensity of the sun is up to 80000Lux | |||||
| Calibration | Calibration free | |||||
| Touch Times | More than 60 million times in the same position | |||||
| Touch Power supply Mode | USB 5.0V power supply | |||||
| Android Specs | Android Frequency | 4*A76(Max:2.4GHz)+4*A55(Max:1.8GHz) | ||||
| System Version | Android 15 | |||||
| Memory | DDR4 16G | |||||
| FLASH | 256G | |||||
| WIFI | WIFI6 | |||||
| Bluetooth | 5 | |||||
| Back port | Input | LAN IN | 2 | |||
| HDMI 2.0 | 3 | |||||
| RS-232 | 1 | |||||
| USB 3.0 | 2 | |||||
| USB 2.0 | 1 | |||||
| DP IN | 1 | |||||
| MIC IN | 1 | |||||
| TF-card | 1 | |||||
| Type-C | 1 | |||||
| OUT | HDMI OUT | 1 | ||||
| PDIF OUT | 1 | |||||
| LINE OUT | 1 | |||||
| Type-C OUT | 1 | |||||
| TOUCH OUT | 1 | |||||
| Front port and function | USB3.0 | 3 | ||||
| HDMI 2.0 | 1 | |||||
| USB TOUCH | 1 | |||||
| Type-C | 1 | |||||
| Front button | Power Button On/Off | 1 | ||||
| Voice+ | 1 | |||||
| Voice- | 1 | |||||
| Annotation | 1 | |||||
| Input | 1 | |||||
| home | 1 | |||||
| Touch Lock | 1 | |||||
| Module | Automatic photosensitive | 1 | ||||
| Auto pen pick up detection | 1 | |||||
| Accessories | Magnetic whiteboard Pen X1pc, Wall-Mount Bracket X1set, Power Cord X1pc, Remote Control X1pc,WiFi antenna X4pcs | |||||
| Others | Power consumption of the whole machine (excluding OPS) | ≤200W | TBD | ≤345W | ≤345W | |
| Standby consumption | ≤0.5W | ≤0.5W | ≤0.5W | ≤0.5W | ||
| Lifetime | 30000 hours | 30000 hours | 30000 hours | 30000 hours | ||
| power supply | 100-240V, 50/60Hz | 100-240V, 50/60Hz | 100-240V, 50/60Hz | 100-240V, 50/60Hz | ||
| Demission | 1485.2*903.36*97.8（mm） | 1707.6*1029.08*97.8（mm） | 1953.56*1168.38*97.8（mm） | 1953.56*1168.38*97.8（mm） | ||
| VESA hole site | 4-M8 hole site 500mm*400mm | 4-M8 hole site 700mm*400mm | 4-M8 hole site 800mm*600mm | 4-M8 hole site 800mm*600mm | ||
| Net Weight | TBD | TBD | TBD | TBD | ||
| Gross Weight | TBD | TBD | TBD | TBD | ||
| package size | 1580*185*1015（mm） | 1815*185*1145（mm） | 2050*200*1295（mm） | 2050*200*1295（mm） | ||
| Built-in camera | 8000*6000（48 million pixels） | |||||
| Built-in microphone | 8 array high-resolution microphones | |||||
| PC （Optional） | PC Option | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | |
| Input Voluge | 18V DC | 18V DC | 18V DC | 18V DC | ||
| Rated Output Current | 4.5A | 5.5A | 6A | 6A | ||
| Rated Load Power | 83W | 99W | 108W | 108W | ||
| lnterface | Canform to Intel® OPS-C JAE 80-pin connector | |||||
| National standard OPS size | L194.6*W179.8*H42mm（42mm or 30mm） | |||||
| European standard OPS size | L180*W119*H30mm | |||||
