Apollo Dazzleview AIP3588 AI Smart Board
AIP3588
Copied!
Key Features
Key Features:
- 4K Ultra HD display (55”–98”) with bright, wide-view screen
- 20-point fast infrared touch with high accuracy
- Android 13 system with powerful CPU, up to 512GB storage
- Wi-Fi 6 + Bluetooth 5.2 for smooth connectivity
- Multiple ports: HDMI, Type-C, USB, DP, VGA, LAN
- Anti-glare durable glass with long lifespan (30,000 hours)
- OPS PC support for easy upgrade and expansion
Powerful RK3588 processor with 6Tops AI performance for multitasking.
Integrated ChatGPT and OpenAI for intelligent, interactive educational support.
AI-driven file analysis and summarization for instant knowledge acquisition.
Effortless voice control for hands-free whiteboard operations and application startup.
Real-time video subtitles and translation for barrier-free global communication.
Secure NFC and fingerprint login for quick, seamless account access.
Technical Specifications
| Interactive Flat Panel (T Series 3588 XS-Q )（F） | ||||||||
| Model | AP55HT | AP65HT | AP75HT | AP85HT | AP86HT | AP98HT | ||
| Display Parameter | Diagonal Size | 55inch |  65inch | 75inch | 85inch | 86inch | 98inch | |
| Effective Display Area | 1209.6(H)*680.4(V) | 1428.48(H)*803.52(V) | 1650.24(H)×928.26(V) | 1872(H)×1053(V) | 1895(H)×1066(V) | 2158.85(H)*1214.35(V) | ||
| Display Ratio | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | ||
| Brightness | 320cd/㎡ | 320cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | ||
| Contrast Ratio | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 1200:1 | ||
| Backlight Type | DLED | DLED | DLED | DLED | DLED | DLED | ||
| Viewing Angle | 178°(V)/178°(H) | 178°(V)/178°(H) | 178°(V)/178°(H) | 178°(V)/178°(H) | 178°(V)/178°(H) | 178°(V)/178°(H) | ||
| Resolution | 3840（H) X 2160(V) | 3840（H) X 2160(V) | 3840（H) X 2160(V) | 3840（H) X 2160(V) | 3840(H) X 2160(V) | 3840（H) X 2160(V) | ||
| Audio Output Power | 8Ω/15W*2 | 8Ω/15W*2 | 8Ω/15W*2 | 8Ω/15W*2 | 8Ω/15W*2 | 8Ω/15W*2 | ||
| Touch | Touch technology | Infrared Multi Touch Technology | ||||||
| Touch Points | 20 points touch | |||||||
| Drive | HID drive free | |||||||
| Writing surface material | 4mm Ag anti glare glass | |||||||
| Touch Screen Sensor Mode | Finger, writing pen, hand with gloves or other non transparent touch sensitive medium | |||||||
| Resolution | 32768X32768 | |||||||
| Communication Port | USB 2.0 | |||||||
| Min Recognition Dim | 2mm | |||||||
| ResponseTime | ≤5ms | |||||||
| Touch Accuracy | ±1mm | |||||||
| Anti-Interference | Incandescent lamp (220V, 100W), vertical distance 350mm above, The illumination intensity of the sun is up to 80000Lux | |||||||
| Calibration | Calibration free | |||||||
| Touch Times | More than 60 million times in the same position | |||||||
| Touch Power supply Mode | USB 5.0V power supply | |||||||
| Android Specs | Android Frequency | 4*A76+4*A55(2.2~ 2.4GHz) | ||||||
| System Version | Android 13 | |||||||
| Memory | DDR4 32G | |||||||
| FLASH | 512G | |||||||
| WIFI | WiFi6 | |||||||
| Bluetooth | 5.2 | |||||||
| Back port | RJ45 IN | 1 | ||||||
| MIC IN | 1 | |||||||
| VGA IN | 1 | |||||||
| VGA AUDIO IN | 1 | |||||||
| RS232 | 1 | |||||||
| HDMI IN | 3 | |||||||
| DP IN | 1 | |||||||
| TYPE-C IN | 1 | |||||||
| USB3.0 | 3 | |||||||
| TF CARD | 1 | |||||||
| RJ45 OUT | 1 | |||||||
| SPDIF OUT | 1 | |||||||
| Earphone | 1 | |||||||
| HDMI OUT | 1 | |||||||
| TYPE C OUT | 1 | |||||||
| Touch OUT | 3 | |||||||
| Front port and function | USB3.0 | 3 | ||||||
| HDMI 2.0 | 1 | |||||||
| USB TOUCH | 1 | |||||||
| Type-C | 1 | |||||||
| Front button | Power Button On/Off | 1 | ||||||
| Accessories | Magnetic whiteboard Pen X1pc, Wall-Mount Bracket X1set, Power Cord X1pc, Remote Control X1pc,WiFi antenna X4pcs | |||||||
| Others | Power consumption of the whole machine (excluding OPS) | TBD | ≤200W | ≤250W | ≤345W | ≤345W | TBD | |
| Standby consumption | ≤0.5W | ≤0.5W | ≤0.5W | ≤0.5W | ≤0.5W | ≤0.5W | ||
| Lifetime | 30000 hours | 30000 hours | 30000 hours | 30000 hours | 30000 hours | 30000 hours | ||
| power supply | 100-240V, 50/60Hz | 100-240V, 50/60Hz | 100-240V, 50/60Hz | 100-240V, 50/60Hz | 100-240V, 50/60Hz | 100-240V, 50/60Hz | ||
| Demission | TBD | 1485.2*890.8*97.8（mm） | 1707.6*1016.55*97.8（mm） | 1953.56*1155.85*97.8（mm） | 1953.56*1155.85*97.8（mm） | TBD | ||
| VESA hole site | 4-M8 hole site 400mm*400mm | 4-M8 hole site 500mm*400mm | 4-M8 hole site 700mm*400mm | 4-M8 hole site 800mm*600mm | 4-M8 hole site 800mm*600mm | 4-M8 hole site 900mm*600mm | ||
| Net Weight | TBD | TBD | TBD | TBD | TBD | TBD | ||
| Gross Weight | TBD | TBD | TBD | TBD | TBD | TBD | ||
| package size | TBD | 1580*185*1015（mm） | 1815*185*1145（mm） | 2050*200*1295（mm） | 2050*200*1295（mm） | TBD | ||
| PC（Optional） | PC Option | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | H81/H110/H310 Mainboard | |
| Input Voluge | TBD | 18V DC | 18V DC | 18V DC | 18V DC | TBD | ||
| Rated Output Current | TBD | 4.5A | 5.5A | 6A | 6A | TBD | ||
| Rated Load Power | TBD | 83W | 99W | 108W | 108W | TBD | ||
| lnterface | Canform to Intel® OPS-C JAE 80-pin connector | |||||||
| National standard OPS size | L194.6*W179.8*H42mm（42mm or 30mm） | |||||||
| European standard OPS size | L180*W119*H30mm | |||||||
