Apollo AIP-Elite8 Interactive Flat Panel
Key Features
- Ultra HD 4K Display (3840 × 2160) for crystal-clear visuals
- Available in 65", 75", 85" sizes for different room scales
- High brightness 450 cd/m² for clear visibility in bright environments
- Wide 178° viewing angle for comfortable viewing from any position
- Fast 6ms response time for smooth display performance
- IR Touch Technology (up to 20-point touch, optional 40-point)
- Anti-glare 4mm tempered glass for durability & eye comfort
- Android 8.0 system with powerful chipset (A73 + A53 cores)
- Built-in OPS slot (Windows support optional: i3/i5/i7)
- Multiple connectivity ports (HDMI, USB, LAN, VGA, etc.)
- Dual 15W speakers for clear audio output
- 18-hour continuous operation (24/7 capable design)
- Long lifespan: 50,000+ hours usage
Write easily
Advanced 20 points touch would offer you an intuitive, natural writing experience in your classroom.
Android 8.0
Switch with a tap between Android OS and Windows 10 OS seamlessly.
Screen mirroring and sharing
4 devices can be showed on panel simultaneously. Just bring your own devices (BYOD).
Technical Specifications
Product Main Parameter | |||
Model | AP65A8 | AP75A8 | AP85A8 |
Backlight | LED | ||
Active Screen Size | 65” | 75” | 85” |
Display Ratio | 16：9 | ||
Resolution | 4k 3840(H)*2160(V) | ||
Colors | 8 bit / 1.08 billion colors | ||
Brightness | 450cd/m2 | ||
Contrast | 5000:1 | 6000：1 | 5000：1 |
Response Time | 6ms | ||
Viewing Angle | 178 degrees | ||
Life Time | 50000Hrs≥ | ||
Speaker | 15W*2 | ||
OPS Slot | Yes | ||
Power Consumption | Maximum<220W, Eco<100W, Standby Mode<0.5W | Maximum<250W, Eco<125W, Standby Mode<0.5W | Maximum<350W, Eco<225W, Standby Mode<0.5W |
Power Voltage | AC 100-240V, 50/60Hz 15W*2 | ||
Working Temperature/Humidity | 0~40℃ / 20%~80% | ||
Max. Continue Working Time | 18 hours*7 days | ||
Android System | |||
System Configuration | Android8.0, MSD848 (8386)chips,Dual croe Cortex A73 and Dual-core A53 1.5 HZ,G51mp2,2G DDR4,16GB flash built in,Max 128GB SD card | ||
Interface Inputs/Outputs | LAN*2,VGA IN*1,PC-AUDIO IN*1,YPBPR*1,AV IN*1,AV out*1,Earphone out *1,RF-in*1,SPDIF*1,HDMI IN*1, TOUCH USB*1,RS-232*1,USB 2.0*2,HDMI OUT*1(OPTIONAL) | ||
Touch Screen Parameter | |||
Glass Surface | 4 mm tempered glass (Anti-glare/option) | ||
Technology | IR | ||
HID Support | Yes | ||
Touch Supported | IR 20 points touch, optional support for 40 touch recognition (additional parts required) | ||
Writing Tools | finger or any opaque object | ||
Positioning Accuracy | ≥3 mm | ||
Response Time | ≤ 5ms | ||
Connection Interface | USB | ||
Detachable IR Frame | Yes | ||
Software | Yes | ||
Touch Life Expectancy | ≥60,000,000 times | ||
OPS (optional) | |||
Chipset | Intel H110 Express | ||
CPU | i3 Intel Skylake | i5 Intel Skylake | i7 Intel Skylake |
Storage | 4G DDR4 RAM / SSD128G/256G | ||
Graphics | Intel IntelHD | Intel IntelHD | NIVIDA GT 1030 2G (i7) |
Interface | USB2.0*4, USB3.0*2, RJ45*1, HDMI*1, DP OUT*1, LINE OUT*1, MIC IN*1, WIFI, COM (option) | ||
OS | Windows 10 | ||
Packing Details | |||
Accessories | Pen*1,Wifi Antanna*3,Remote controller*1, Power cable 1.5*1, User manual*1, Wall bracket*1,Pressure pen*1(optional),wireless presentation system*1(optional) | ||
Packing Dimension (mm) | 1600*215*2015 | 1870*220*1150 | 2110*240*1315 |
Net Weight | 41Kg±1.5Kg | 58.6Kg±1.5Kg | 92.7Kg±1.5Kg |
Gross Weight | 50Kg±1.5Kg | 69.7Kg±1.5Kg | 110Kg±1.5Kg |
Product Dimension(mm) | 1485.6*903*109.6 | 1725*1042.6*109.5 | 1961*1183.5*125.6 |
