Apollo AIP-edu Interactive Flat Panel for Education
Key Features
- 4K Ultra HD display (3840×2160) with high brightness (450 nits)
- Premium visual clarity with 5500:1 contrast ratio
- Smooth touch experience with 20-point IR multi-touch (optional 40-point)
- Fast response time (≤5ms touch / 6ms display)
- Durable 4mm anti-glare tempered glass
- Powerful dual speakers (2×20W)
- Built-in Android system for basic operations
- Wide connectivity: HDMI, USB, VGA, AV, LAN, RS232, SPDIF
- OPS slot support for Intel i3/i5/i7 PC upgrade
Write easily
Advanced 20 points touch would offer you an intuitive, natural writing experience in your classroom.
Dual OS
Switch with a tap between Android OS and Windows 10 OS seamlessly.
Best grade 4K screen
50,000 hours of reliable use promise. No more lamp replacement cost as your traditional projector.
Technical Specifications
Product Main Parameter | |||
Model | TP65 | TP75 | TP85 |
Slime Frame (mm) | 25 | ||
Backlight | LED | ||
Active Screen Size | 65” | 75” | 86” |
Display Ratio | 16:09 | ||
Resolution | 4k 3840(H)*2160(V) | ||
Colors | 8 bit / 1.08 billion colors | ||
Brightness | 450cd/m2 | ||
Contrast | 5500:01:00 | ||
Response Time | 6ms | ||
Viewing Angle | 178 degrees | ||
Life Time | 50000Hrs≥ | ||
Speaker | 20W*2 | ||
OPS Slot | Yes | ||
Power Voltage | AC 100-240V, 50/60Hz 15W*2 | ||
Tmperature/Humidity | 0~40℃ / 20%~80% | ||
Max. Continue Working Time | 18 hours*7 days | ||
Power Consumption | Maximum<220W, Eco<100W, Standby Mode<0.5W | Maximum<250W, Eco<125W, Standby Mode<0.5W | Maximum<350W, Eco<225W, Standby Mode<0.5W |
Android System | |||
System Configuration | Android 5.1, CPU MSD6A638/828, RAM 1G/2G, Flash 4GB | ||
Interface Inputs/Outputs | HDMI*2 (1 for OPS), RJ45*1, Touch USB*1, USB2.0*3 (front*1), SPDIF OUT*1, RS232*1, SD*1, VGA IN*1, RF*1, AV IN*2, Audio IN*1, WIFI*1, AV OUT*1, VGA OUT*1, Headphone jack*1, YPbPr IN*1, Audio OUT*1, MIC*1 | ||
Touch Screen Parameter | |||
Glass Surface | 4 mm tempered glass (Anti-glare/option) | ||
Technology | IR | ||
HID Support | Yes | ||
Touch Supported | 20 points touch, optional support for 40 touch recognition (additional parts required) | ||
Writing Tools | finger or any opaque object | ||
Positioning Accuracy | 3 mm | ||
Response Time | ≤ 5ms | ||
Connection Interface | USB | ||
Detachable IR Frame | Yes | ||
Software | Yes | ||
Touch Life Expectancy | ≥60,000,000 times | ||
OPS (optional) | |||
Chipset | Intel H110 Express | ||
CPU | i3 Intel Skylake | i5 Intel Skylake | i7 Intel Skylake |
Storage | 4G DDR4 RAM / SSD128G | ||
Graphics | Intel IntelHD | Intel IntelHD | NIVIDA GT 1030 2G (i7) |
Interface | USB2.0*4, USB3.0*2, RJ45*1, HDMI*1, DP OUT*1, LINE OUT*1, MIC IN*1, WIFI, COM (option) | ||
OS | Windows 10 | ||
Packing Details | |||
Accessories | Remote controller*1, Power cable 1.5*1, User manual*1, Wall bracket*1 | ||
Packing Dimension (mm) | 1600*1025*215 | 1870*1150*220 | 2110*1315*240 |
Net Weight (kg±4) | 55 | 70 | 86 |
Gross Weight (kg±4) | 60 | 85 | 102 |
Product Dimension (mm) | 1485.6*903*92.5 | 1725*1042.6*88 | 1961*1183.5*110 |
