Apollo AIP-commercial Interactive Flat Panel
Key Features
- 4K Ultra HD display (3840×2160) with high brightness (450 nits)
- Strong visual performance with 5000:1 contrast & 178° viewing angle
- Smooth interaction with IR touch (20-point, optional 40-point)
- Fast touch response (≤5ms) for writing & collaboration
- Durable 4mm anti-glare tempered glass
- Built-in dual speakers (2×15W)
- Slim modern design (25mm frame)
- Android system (7.1) for basic smart features
- Wide connectivity: HDMI, USB, LAN, VGA, Bluetooth, WiFi
- OPS slot support (Intel i3/i5/i7 – Windows upgrade ready)
- Long lifespan (50,000+ hours)
- Designed for heavy usage (up to 18 hrs/day)
Full 4K screen with 12mm ultra-slim frame
Built-in Camera and Microphone Array
Magnetic Pen Slot ready to be picked up
Cinema-level surround stereo sound
Technical Specifications
Product Main Parameter | |||
Model | AP65 Pro | AP75Pro | AP85Pro |
Slime Frame (mm) | 25 | ||
Backlight | LED | ||
Active Screen Size | 65” | 75” | 86” |
Display Ratio | 16:09 | ||
Resolution | 4k 3840(H)*2160(V) | ||
Colors | 8 bit / 1.08 billion colors | ||
Brightness | 450cd/m2 | ||
Contrast | 5000:1 | ||
Response Time | 6ms | ||
Viewing Angle | 178 degrees | ||
Life Time | 50000Hrs≥ | ||
Speaker | 15W*2 | ||
OPS Slot | Yes | ||
Power Consumption | Maximum<220W, Eco<100W, Standby Mode<0.5W | Maximum<250W, Eco<125W, Standby Mode<0.5W | Maximum<350W, Eco<225W, Standby Mode<0.5W |
Power Voltage | AC 100-240V, 50/60Hz 15W*2 | ||
Working Temperature/Humidity | 0~40℃ / 20%~80% | ||
Max. Continue Working Time | 18 hours*7 days | ||
Android System | |||
System Configuration | Android 7.1, CPU RTD2861R, RAM 2G/16G | ||
Interface Inputs/Outputs | HDMI*2, RJ45*2, Touch USB*1, USB2.0*2, USB3.0*1,SPDIF OUT*1, RS232*1, SD*1, VGA IN*1, Audio IN*1, WIFI*2,VGA AUDIO IN*1, Headphone jack*1, MIC*1,buletooth*1,USB Extension*2 | ||
Touch Screen Parameter | |||
Glass Surface | 4 mm tempered glass (Anti-glare/option) | ||
Technology | IR | ||
HID Support | Yes | ||
Touch Supported | 20 points touch, optional support for 40 touch recognition (additional parts required) | ||
Writing Tools | finger or any opaque object | ||
Positioning Accuracy | 3 mm | ||
Response Time | ≤ 5ms | ||
Connection Interface | USB | ||
Detachable IR Frame | Yes | ||
Software | Yes | ||
Touch Life Expectancy | ≥60,000,000 time | ||
OPS(Optional) | |||
Chipset | Intel H110 Express | ||
CPU | i3 Intel Skylake | i5 Intel Skylake | i7 Intel Skylake |
Storage | 4G DDR4 RAM / SSD128G | ||
Graphics | Intel IntelHD | Intel IntelHD | NIVIDA GT 1030 2G (i7) |
Interface | USB2.0*4, USB3.0*2, RJ45*1, HDMI*1, DP OUT*1, LINE OUT*1, MIC IN*1, WIFI, COM (option) | ||
OS | Windows 10 | ||
Packing Details | |||
Accessories | Remote controller*1, Power cable 1.5*1, User manual*1, Wall bracket*1,Pressure pen*1(optional),wireless presentation system*1(optional) | ||
Packing Dimension (mm) | 1600*1025*215 | 1870*1150*220 | 2110*1315*240 |
Net Weight (kg±4) | 41 | 58.6 | 92.7 |
Gross Weight (kg±4) | 50 | 69.7 | 110 |
Product Dimension(mm) | 1485.6*903*94.6 | 1725*1042.6*109.6 | 1961*1183.5*125.7 |
