Apollo AIP-Black Android 8.0 series Interactive Flat Panel
Key Features
- 4K Ultra HD display (3840×2160) with TCL CSOT panel
- Wide 178° viewing angle for clear visibility from any side
- Smooth performance with Quad-core CPU & Android 8.0
- High brightness (350 nits) & strong contrast (up to 6000:1)
- Infrared multi-touch with fast 6ms response
- Durable metal body with premium build quality
- Built-in dual speakers (up to 2×25W on 98”)
- Multiple connectivity: HDMI, USB, Type-C, LAN, VGA, AV, RS232
- OPS slot support for Windows PC integration
- Long usage support (up to 18 hours/day)
- Energy efficient with low standby (<0.5W)
- Complete accessories included (pen, wall mount, remote, WiFi antenna)
Front facing Type C, HDMI and USB ports.
Black super slim frames to make the full 4K screen catch eyes.
Built-in 8 mega-pixel Camera and Microphone Array as optional.
Magnetic Pen Slot ready to be picked up.
Screen mirroring and sharing from 4 devices simultaneously. Just (BYOD).
Technical Specifications
Product Main Parameter | ||||
Model | AP-65B | AP-75B | AP-85B | AP-98B |
Size | 65" | 75” | 85” | 98” |
Overall Size | 1479.9*923.6*106.1 mm | 1699.2*1038.1*106.5 mm | 1946*1181.8*113.15 mm | 2227.4*1345.8*122 mm |
Packing Size | 1600*1025*215 mm | 1870*1150*220 mm | 2110*1315*240 mm | 2500*1630*440 mm |
G.W/N.W | 52/43 KG±1.5KG | 69/58 KG±1.5KG | 110/92.7 KG±1.5KG | 197/139 KG±1.5KG |
Screen Manufacturer | TCL CSOT | |||
Backlight Type | D-LED | |||
Resolution | 3840*2160 | |||
Brightness | 350cd/m² | |||
Contrast Ratio | 4000:1 | 6000:1 | 4000:1 | 1200:1 |
Response Time | 6ms | |||
Dot Pitch | 0.124*0.372 mm (H*V) | 0.4298*0.4298 mm (H*V) | 0.4875*0.48758 mm (H*V) | 0.5622*0.5622 mm (H*V) |
Refresh Rate | 60 Hz | |||
View Angle | 178°(H) / 178°(V) | |||
Saturation (x% NTSC) | 72% | |||
Display Area | 1428.48 (H)*803.52 (V) mm | 1650.24 (H)*928.26 (V) mm | 1872 (H)*1053 (V) mm | 2158.85 (H)*1214.35 (V) mm |
Colors | 1.07B(8bit) | |||
Screen Lifespan | 30,000 hrs | |||
Android System | ||||
Chipset | MSD8386 | |||
Android Version | Android 8.0 | |||
CPU | CA53*2+CA73*2 | |||
CPU Base Frequency | 1.5 GHz | |||
# of Cores | Quad-core | |||
GPU | G51MP2 | |||
RAM | 2 GB DDR4 | |||
ROM | 16 GB Standard | |||
Power | ||||
Input Voltage | 100 V ~ 240 V/AC, 50/60 Hz | |||
Max Consumption (without OPS) | ≤220W | ≤300W | ≤350W | ≤450W |
OPS Power Input | 19V(DC)/5A | |||
Standby Consumption | <0.5W | |||
Power Input Port (AC) | *1 | |||
TV System | ||||
TV | ATV (PAL,SECAM) | |||
DTV (DTMB) | ||||
Speaker | 8Ω/10W*2 | 8Ω/10W*2 | 8Ω/10W*2 | 8Ω/25W*2 |
Power On/Off | *1 | |||
Video Decoding | Image denoising, image self-adaptive filtering, etc. | |||
Channel | 200 | |||
Stereo Amplifier System | Yes | |||
I/O Connectors | ||||
LAN | *2 | |||
VGA IN | *1 | |||
PC-AUDIO IN | *1 | |||
YPBPR | *1 | |||
AV IN | *1 | |||
AV OUT | *1 | |||
Earphone OUT | *1 | |||
RF-IN | *1 | |||
SPDIF | *1 | |||
HDMI IN | *3 (1 front) | |||
Touch | *2 (1 front) | |||
Type-c | *1 (front) | |||
RS-232 | *1 | |||
USB2.0 | *5 (3 front dual-channel USB2.0) | |||
Environment | ||||
Working TEMP | 0℃ ~ 40℃ | |||
Storage TEMP | -10℃ ~ 60℃ | |||
Working Humidity | 20% ~ 80% | |||
Storage Humidity | 10% ~ 60% | |||
Recommended Max Usage Time | 18Hours*7days | |||
VESA Hole | 4-M8 screw hole 400mm*200mm | |||
Shell Material | aluminum alloy/metal plate | |||
Shell Color | black | |||
OSD Menu | 10 languages (English, Chinese, etc.) | |||
Packing Details | ||||
Wifi Antenna | *3 | |||
Touch Pen | *1 | |||
Remote Control | *1 | |||
User Manual | *1 | |||
3m Power Cable | *1 | |||
Wall Mount Bracket (include screws) | *1 (set) | |||
