Apollo AIP-XM01 Wireless Screen Sharing Dongle
AIP-XM01
Copied!
Key Features
- Full HD output (1920×1080) with high input support up to 1920×1200
- Supports up to 8 simultaneous input sources
- Ultra-low latency transmission (<120ms) for smooth sharing
- Dual-band wireless (2.4GHz & 5GHz – 5GHz recommended)
- Wireless range up to 15 meters (100 ft)
- Cross-platform support: Windows & macOS compatible
- Smooth video performance up to 30fps (iOS) / 25fps (Windows)
- Plug & play USB 2.0 connectivity
- Secure connection with WPA2-PSK & CCMP encryption
- Wireless speed up to 54Mbps (IEEE 802.11 a/g/n)
- Very low power consumption (2.5W, 5V DC)
- Compact & lightweight design (63.3g only)
1. One-Click Projection
Instant Setup: Mirror devices to any screen in seconds.
Zero Delays: HD clarity with seamless streaming.
2. Real-Time Touch Control
Sync Edits: Modify slides on any screen with live updates.
Touchback Tech: Swipe or annotate displays to control devices.
3. Cross-Platform Freedom
Full OS Support: Windows, macOS, iOS, Android.
Stream Anywhere: TVs, projectors, video walls.
Technical Specifications
Technical Specifications
3.1 Hardware Parameters
| Parameter | Specification |
|---|---|
| Input Resolution | 1920×1200 |
| Output Resolution | 1920×1080 |
| Simultaneous Input Sources | 8 |
| Interface | USB 2.0 ×1 |
| Input Voltage | 5V-DC |
| Power Consumption | 2.5W |
3.2 System Configuration
| Parameter | Specification |
|---|---|
| Transmission Delay | <120ms |
| Supported OS | Windows 7/8/10, Mac OS X 10.6/10.7 |
| Computer Requirements | |
| CPU | Intel Pentium Dual Core E2140 / AMD Athlon 64 X2 3800+ |
| RAM | 1024 MB (2GB+ recommended for Windows 7) |
| Security | |
| Encryption | CCMP |
| Authentication Protocol | WPA2-PSK |
| Wireless Protocol | IEEE 802.11 a/g/n |
| Wireless Data Rate | 54Mbps |
| Frame Rate | |
| Windows | 25fps (1920×1080 / 1366×768) |
| iOS | 30fps (1920×1080 / 1366×768) |
3.3 Environmental Parameters
| Parameter | Specification |
|---|---|
| Operating Temp | +5℃ ~ +40℃ |
| Storage Temp | -20℃ ~ +60℃ |
| Operating Humidity | 0–80% RH |
| Storage Humidity | 0–95% RH |
| Wireless Range | 15m (100ft) |
| Frequency Band | 2.4GHz & 5GHz (5GHz recommended) |
3.4 Device Specifications
| Parameter | Specification |
|---|---|
| Net Weight | 63.3g |
| Device Dimensions | 61×156×17mm |
| Package Size | 90×190×45mm |
| Included Accessories | User manual, Receiver rod (optional) |
