Apollo AIP-D2 Screen Share QuickShare Wireless receiver dongle
AIP-D2
Copied!
Key Features
- Full HD 1080P output with 60Hz smooth display
- Ultra-low latency (50–150ms) for real-time screen sharing
- Dual connectivity: USB 2.0 + HDMI 1.4
- Supports Windows, macOS, Android & iOS devices
- Wireless transmission up to 8 meters (line of sight)
- Dual mode operation: P2P & AP hotspot mode
- Secure connection with AES encryption & WPA2-PSK authentication
- Supports extended desktop mode (Windows & macOS)
- Compact & lightweight design (only 26g)
- Low power consumption (2.5W, USB powered 5V)
- Plug & play operation with single-button control
- Supports up to 4 simultaneous connections in hotspot mode
SUPPORTS AIRPLAY DIREC
DUAL MIRACAST P2P SCREEN MIRRORING
NO INTERNET CONNECTION
NO SOFTWARE INSTALLATION
WORKS WITH WINDOWS, MACOS IOS, ANDROID, AND HARMONYOS
SIMPLY CONNECT AND CAST AIRPLAY AND MIRACAST FOR DIRECT SCREEN CASTING
Technical Specifications
Hardware Specifications
| Specification | Details |
|---|---|
| Connection Ports | USB 2.0, HDMI 1.4 |
| Max Concurrent Connections | 4 (In hotspot mode) |
| Display Mode | Single screen |
| Input Voltage | 5V |
| Input Current | 500mA |
| Power Consumption | 2.5W |
| Weight | 26g (±2g) |
| Product Dimensions | 90mm × 33mm × 12mm (±2mm) (L*W*H) |
| Package Dimensions | 208mm × 108mm × 32mm (±2mm) (L*W*H) |
| Operating Temperature | 0℃ to +40℃ |
| Storage Temperature | -10℃ to +60℃ |
| Indicator Light | Blue |
| Appearance Color | Black |
| Button Interface | One |
System Parameters
| Parameter | Details |
|---|---|
| Transmission Latency | 50-150ms |
| Output Resolution | 1080P |
| Frame Rate | 60Hz |
| Supported OS | Windows 7/8/10/11, macOS 10.11+, iOS 10.9+, Android 5.0+ |
| Display Modes | Supports extended desktop on Windows/macOS |
| Operating Mode | P2P mode, AP hotspot mode |
| Wi-Fi Band | 5G |
| Encryption | AES |
| Authentication Protocol | WPA2-PSK |
| Transmission Distance | Up to 8m (line of sight) |
