Apollo AIP-IN-Display Smart Screen Video Camera
Key Features
- Full HD 2.1MP Sony CMOS sensor (1/2.9")
- Available in 3x Optical Zoom & 10x Optical Zoom models
- Low light performance: 0.1 Lux (F1.6) for clear indoor use
- Full HD 1080P video output (MJPEG up to 1080P30)
- Wide viewing flexibility (up to 84° / 54° HOV depending on model)
- Smooth PTZ control (Pan: ±75°, Tilt: ±30°)
- 64 preset positions for quick camera switching
- Supports UVC / VISCA / PELCO-D protocols (easy integration)
- Auto white balance, auto gain & backlight compensation
- IR wireless remote control for easy operation
- USB 2.0 plug-and-play connectivity
SONY 1/2.9” CMOS Sensor
3x and 10x optical zooms optional
USB2.0 interface,
Output 1080p@30fps Full hd image
Field of view:84 degree and 54 degree optional
Technical Specifications
Model | 3x Zoom | 10x Zoom |
Image Sensor | ||
Sensor | 1/2.9" SONY CMOS | |
Effective Pixel | 2.1 Megapixel | |
Min Illumination | 0.1Lux at F1.6 | |
White Balance | Auto/Indoor/Outdoor/ATW | |
Gain Control | Auto | |
Back Light Compensation | Support | |
Electronic Shutter | Support | |
SN Ratio | >50db | |
Lens | ||
Focus | f=3.3mm-10mm | f=4.7mm-47mm |
Iris | F1.7-F3.0 | F1.6-F2.5 |
Zoom | 3x Optical Zoom | 10x Optical Zoom |
HOV | 84° | 54° |
Video Output Interface | USB2.0 Type B | |
Video Output Format | MJPEG:1080P30/25，720P30/25，640*480，640*360 | |
Communication Protocol | VISCA，PELCO-D，UVC | |
Baud Rate | 9600bps/38400bps | |
Preset Position | 64 | |
OSD Menu | Support | |
Image Flip | Support mirrors image, flipping | |
Pan Movement Speed | 1-40°/S | |
Pan movement | -75°~ +75° | |
Tilt Movement | 30°(Up)，30°(Down) | |
Remote Controller | IR Wireless Remote Controller P/T/Z | |
Power Supply | USB2.0 Power supply (with auxiliary power supply） | |
Work Temperature | 0-50℃ 0-95% RH | |
L x W x H | 350mm*112mm*139mm | |
Weight | 785g | 785g |
