Apollo AIP-55FDK Floor stand digital Kiosk & Portable Display
AIP-55FDK
Copied!
Key Features
- 55-inch Full HD vertical display (1080 × 1920, 9:16 portrait mode)
- Commercial-grade LED panel (new original factory screen)
- Ultra-slim design with 83.2mm body thickness
- ≥300 cd/m² brightness for clear indoor visibility
- 16.7M colors (8-bit) for natural image quality
- Wide 178° viewing angle (89/89/89/89)
- Android 9.0 operating system built-in
- Quad-core Cortex-A53 processor (1GHz)
- 1GB RAM + 8GB internal storage
- Supports Ethernet + WiFi connectivity
- Dual USB + HDMI + RJ45 input ports
Plug and Play with Centralized Management
Easily foldable and portable
24/7 Commercial Grade
Toughened Safety Glass
Technical Specifications
| LCD size | 55 inches |
| LCD | New original factory packaged LED commercial LCD panel |
| resolution ratio | 1080*1920 |
| Display area | 679*1208mm（H×V） |
| Aspec Ratio | 9:16 |
| View Angle | 89/89/89/89 (left/right/up/down) |
| luminance | ≥300cd/m2 |
| Backlight type | E-LED |
| Coloration | 16.7M（8-bit） |
| service frequency | 60HZ |
| Pixel arrangement | RGB vertical bar installation |
| operating system | android |
| System version | Android 9.0 |
| CPU | The four-core Cortex-A53 has a main frequency of 1GHz |
| internal storage | 1GB |
| memory | 8GB |
| system interface | USB port *2, RJ45 port *1, HDMI-IN port *1 |
| Video playback | Supports wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 and other formats |
| Image credit | Supports BMP, JPEG, PNG, GIF and other formats |
| Internetwork | Support Ethernet and WIFI |
| Turn on and off at regular intervals | Supports custom setting of startup and shutdown time |
| Mouse and keyboard | Support hot plug-in |
| Sound power | 8Ω5W*2 |
| Third party applications | Support third-party applications |
| Border material | alufer |
| Border color | black |
| The color of fuselage | Black |
| armoured glass | High strength explosion-proof tempered glass with thickness of more than 3mm |
| Body size | 758.6*1850*83.2mm |
| packing measurement | 890mm*1950mm*180mm |
| Packaging material | Gravity neutral carton |
| Weight of the fuselage | 28.9kg |
| Including packaging weight | 34kg |
| way to install | Laid flat |
| usage scenario | indoor |
| input voltage | AC100-240V，50/60Hz |
| Standby power | ≤1W |
| power rating | ≤75W |
| service environment | Temperature-10℃~50℃ / humidity 10%RH~90%RH |
| Storage environment | Temperature-15℃~65℃/humidity 10%RH~95%RH |
| Accessory | power cable, WiFi antenna, remote control |
